backend_mysql.h File Reference

#include <security/pam_modules.h>
#include <mysql/mysql.h>
#include "pam_kmux_options.h"

Include dependency graph for backend_mysql.h:

This graph shows which files directly or indirectly include this file:

Functions
void *	mysql_db_connect (const modopt_t *options)
	Connect to mysql database.
void	mysql_db_disconnect (void *vconn)
	Terminate database connection.
int	mysql_expand_query (char command, const char values, const char query, const char service, const char user, const char passwd, const char rhost, const char raddr, const modopt_t *options)
	Build a SQL-query. This function build a valid SQL-query. Some variables like u for user or c for column_password are substitutet by their meaning.
int	mysql_exec_param (void vconn, void vres, const char query, const char service, const char user, const char passwd, const char rhost, const modopt_t *options)
	Execute a query on the mysql database.
int	mysql_backend_authenticate (const char service, const char user, const char passwd, const char rhost, const modopt_t *options)
	Authenticate against mysql backend.

Detailed Description

pam_kmux-mysql-API. In this file all mysql-pam-kmux-backend-API-functions are defined.

int mysql_backend_authenticate	(	const char *	service,
		const char *	user,
		const char *	passwd,
		const char *	rhost,
		const modopt_t *	options
	)

Authenticate against mysql backend.

This function tries to finds out the database type given by the modopt_t *options object and run a authentification query on it.

Parameters:

	service	Service character array.
	user	Character array contains username/uid of the user that tries to change password.
	passwd	Character array contains the password of the user.
	rhost	Character array contains the value of PAM_RHOST. This is only needed if you need gsomething like this in your defined queries.
	options	Struct which represents exactly one database connection.

Return values:

	PAM_SUCCESS	Successfully authenticate against backend.
	PAM_AUTH_ERR	Malformed options (passwd, options or user = NULL), connection error during dial-up, password comarison between database-stored-password and entered password fails, or query expandation fails.
	PAM_AUTHINFO_UNAVAIL	Fetched no valid result.

void* mysql_db_connect ( const modopt_t * options )

Connect to mysql database.

This functinos establish a mysql database connection and returns a database handle.

Parameters:

options

A modopt_t struct, which contains the database information will be used establish a database connection.

Returns:: An MYSQL-database-handle if everything is ok, NULL if something went wrong trying to establish a connection.

void mysql_db_disconnect ( void * vconn )

Terminate database connection.

This function takes an MYSQL-database-handle an releases it properly.

Parameters:

vconn

A connection handle to a mysql database.

Execute a query on the mysql database.

This function tries to find out the database type given by the modopt_t *options object and run a query on it.

Parameters:

	vconn	MYSQL-database-connection handle.
	vres	MYSQL_RES-mysql-result..
	query	Contains the unhandled SQL-query (still contains variables like u or c, ...).
	service	Service name character array.
	user	Character array which contains username/uid of the user that tries to change password.
	passwd	The probably hashified password which should be entered into database.
	rhost	Character array contains the value of PAM_RHOST. This is only needed if you need something like this in your defined queries.
	options	Struct which represents exactly one database connection.

Return values:

	PAM_SUCCESS	Successfully executed query.
	PAM_AUTH_ERR	Failure durin password encryption.

Build a SQL-query. This function build a valid SQL-query. Some variables like u for user or c for column_password are substitutet by their meaning.

Parameters:

	command	In this char arry the resulting (expanded) query will be stored.
	values	Array not used in firebird.
	query	Contains the unhandled SQL-query (still contains variables like u or c, ...).
	service	Service name character array.
	user	Character array which contains username/uid of the user that tries to change password.
	passwd	The probably hashified password which should be entered into database.
	rhost	Character array contains the value of PAM_RHOST. This is only needed if you need something like this in your defined queries.
	raddr	Contains the address of rhost
	options	Struct which represents exactly one database connection.

Returns:: This function returns the length of the expanded query. So the returnvalue '0' indicated the occurrence of an error.
